Protection geometry
Use plane, wedged, Brewster, dome or reference-flat geometry according to sealing, field of view and reflection control.
PRODUCT FAMILY
Plane Windows
Plane optical windows protect cameras, sensors and laser assemblies without intentionally changing beam power.
Compare K9 optical glass, UV fused silica and sapphire families by surface precision, parallelism, thickness and environmental durability.
Related families
SELECTION PRIORITIES
Choose plane windows around the optical requirement
8 product families are available. Use the engineering filters below to narrow the catalog before comparing exact models.
Wavefront quality
Check thickness, flatness, parallelism or wedge and surface quality against the transmitted-wavefront requirement.
Material and environment
Balance spectral transmission, thermal expansion, hardness and environmental durability before selecting a coating.
PRODUCT FINDER
Plane Windows
Compare product families, then open a family to select the exact model, dimensions and coating.
8families found
No matching product families on this page
Try another keyword or clear the search field.
SELECTION QUESTIONS
Plane Windows FAQ
Technical answers to the questions that most often affect model selection.
When should I use a plane, wedge or Brewster window?
Choose a plane window for general beam-path protection. A wedged window separates front- and rear-surface reflections to reduce etalons and ghost images. A Brewster window is intended for a defined incidence angle and polarization state where p-polarized reflection must be minimized.
How should window material be selected?
Select the substrate from the required wavelength range, thermal load, mechanical environment and cost target. K9 optical glass serves many visible systems, UV fused silica supports ultraviolet and thermally stable use, and sapphire offers greater hardness and environmental durability.
Which window tolerances affect optical performance?
Transmitted wavefront is influenced by surface flatness, parallelism or wedge, thickness variation and material homogeneity. Surface quality and edge finish matter for scatter, handling and high-power applications. Optical flats additionally require the reference surface grade to match the inspection method.
Need a different diameter, tolerance or coating?
Send your material, wavelength, dimensions and quantity for review.
